Haulotte HA80 RTJ O

New Equipment / Haulotte / Articulating Booms / HA80 RTJ O

Double tap to zoom

Features
Specifications

Features

Product characteristics

Outdoor
Uneven ground
Diesel

Application fields

Finishing
Construction
Landscaping
Maintenance & Renovation
Sporting & other events

Presentation

Performance & Productivity
Safety and Comfort
Minimized Total Cost of Ownership

Specifications

Performance & Productivity

Very good working envelope
Vertical arm rise up
Outstanding RT capabilities
basket load capacity 550 lbs
Dual load 550-770 lbs (option)

Safety and Comfort

Fully proportional and simultaneous movements
Activ' Lighting System safe load (option)
Haulotte Activ' Shield Bar 2.0 (option)

Minimized Total Cost of Ownership

Haulotte Activ' Screen on board diagnostic tool
Haulotte Stop Emission System which automatically turns the engine off & on
Easy access to all components
Modular basket quick and easy to repair

Specifications

Technical data

Working height	86 ft 1 in
Platform height	80 ft 1 in
Horizontal outreach	57 ft 5 in
Up and over clearance	30 ft 6 in
Lift capacity	550 lb (2 pers.) - option: 770lb
Platform size	8 ft x 3 ft
Length	38 ft 8 in
Width	8 ft 2 in
Height - stowed	9 ft 9 in
Storage / transport length	30 ft 10 in
Storage / transport height	9 ft 9 in
Vertical jib rotation	133° (-65°/+68°)
Platform rotation	180°
Turntable rotation	360°continuous
Tailswing	30 in
Wheelbase	9 ft 2 in
Ground clearance	19 in
Tilt	4°
Drive speed	3.1 mph
Maximum wind speed rating	28 mph
Gradeability	45 %
Tires - solid rough terrain	40.4 x 14.4 in
Turning radius - outside	21 ft 6 in
Power source	Kubota 48.6kW (66hp), T4f
Weight	34,100 lb
Hydraulic tank capacity	37 gal
Fuel tank capacity	21 gal
Ground clearance - mini	0 ft
Ground clearance - maxi	0 ft

Standard equipment

Embedded diagnostic system Haulotte Activ' Screen on lower control box, with color screen
Haulotte Stop Emission System : automatic engine stop system
Universal telematics plug
4 wheel drive, 2 wheel steer
Front oscillating axle
4 simultaneous movements
Automatic differential wheel lock
Upper control box cover
Tool tray
Modular standard basket 8 ft x 3 ft
Drop bar entry gate
AC power to platform (110 / 230V)
Swing out engine tray
Tilt / load alarm and light
Rotating beacon
Travel alarm
Electric pump system and emergency descent
12V battery
Engine pre-heater with light indicator
Low fuel level indicator (upper & lower control box)

Main options

Activ' Lighting System, Safe load
Activ' Shield Bar 2.0
Non-marking tires
Dual load capacity 550 / 770 lbs
60 km / h wind speed
Power to platform (female plug in the basket)
Air line to platform
Hydraulic generator 3.5 kW
Biodegradable hydraulic oil
Hydraulic oil cooler
Cold weather kit / Arctic weather kit
Pipe cradle
Glazier pack
Working light
Battery circuit breaker
